STC-ZJ360ATX
Tags: PC Case Gaming, Gaming Computer Case, Wholesale PC Case, Mesh Panel PC Case
Key Features
STC-ZJ360ATX Innovation
Dual-Panel Panoramic Glass
Outfitted with dual tempered glass panels (front and left side) to provide an unobstructed, theater-like showcase of your custom setup.
Trapezoidal PSU Shroud
Features a distinctively shaped trapezoidal power supply compartment built with an integrated, motherboard-syncable RGB strip.
Flagship GPU Space
Despite its space-optimized design, it offers a massive graphics card clearance of up to 460mm, comfortably fitting the largest flagship GPUs.
Extensive 8-Fan Airflow
Engineered to accommodate up to 8 fans simultaneously, ensuring optimal thermal management across all primary zones.
Top 360mm Liquid Cooling
Offers robust cooling versatility, allowing a 240mm, 280mm, or 360mm liquid radiator to be mounted directly on the top panel.
Excellent Tower Clearance
Supports tall CPU air coolers up to 170mm in height, providing compatibility with high-performance air-cooling towers.
Technical Specifications
Product Parameters
| Specification | Details |
|---|---|
| Case Type | Mid-Tower Chassis |
| Model | STC-ZJ360ATX |
| Color | White (as shown; customizable) |
| Dimension | 473mm(L) × 225mm(W) × 485mm(H) |
| Material | 0.5mm SPCC Black + Tempered Glass |
| Panel Design | Left side tempered glass, right side metal panel |
| Special Features | Double-sided tempered glass with trapezoidal LED power shroud |
| Motherboard Support | ATX |
| Expansion Slot | 7 |
| Storage | 1×3.5" HDD + 2×2.5" SSD |
| GPU Length Clearance | Max 460mm |
| CPU Cooler Height Clearance | Max 170mm |
| PSU Support | Standard ATX PSU |
| Fan Support | Mainboard side: 2×120mm (optional)Rear: 1×120mm (optional)Top: 3×120mm/140mm (optional)PSU Top: 2×120mm (optional) |
| Radiator Support | Top: 240mm / 280mm / 360mm (optional) |
| I/O Ports | 1×USB 3.0 + 1×USB 2.0 + HD Audio |
